Technology Overview

USB is simple which is why every device has a USB port on it; your PC, Mac, smartphone, tablet, Chromebook. DisplayLink USB graphics leverages this universal connector to allow docking and graphics across a wide range of platforms. This makes docking as simple as any USB device.

DisplayLink has a range of devices to support different technology needs from USB2 to USB3, Ethernet and a full range of monitors resolution from HD (1920x1080) to UHD (3840x2160), Cinema 4K (4096x2160) and 5K (5120x2880). DisplayLink devices support all common monitor interfaces such as VGA, DVI, HDMI and DisplayPort (DP).

DisplayLink ICs also support different products such as docks, travel docks or graphics adapters.

DisplayLink Integrated Chipsets (ICs)

DisplayLink provide a range of ICs for a single display on USB 2.0, to solutions for 5K displays, USB 3.0 docking and wireless displays.

Compare Our Chipset Series

Chipsets	Target Applications	Maximum Resolution	Supported Displays*	Integrated Network	Integrated Audio
DL-1950	Dual 4Kp60 wireless docking stations	3840x2160 (wireless)	1-2	1Gbps Ethernet	5.1 channels
DL-6000	Dual 4Kp60/5K USB docking stations	5120x2880 (DisplayPort) 4096x2160 (HDMI)	1 - 4	1Gbps Ethernet	5.1 channels
DL-5000	4K USB3 docking stations and adapter	3840x2160 (DisplayPort) 2560x1440 (HDMI) 2048x1152 (VGA/DVI)	1 - 3	1Gbps Ethernet	5.1 channels
DL-4000	USB monitors Meeting room controllers	1920x1080 (LVDS/eDP)	1	No	No
DL-3000	Mid-range USB docking stations and adapters	2048x1152 (VGA/DVI) 2560x1440 (HDMI) 2560x1600 (DisplayPort)	1 - 2	1Gbps Ethernet	5.1 channels
DL-1x5	Entry level USB adapters and displays	1920x1200 (DVI/VGA/TTL/LVDS)	1	No	No

*DisplayLink enabled products can be chained together to expand connectivity where required.
